SKF GE100ES-2RS Bearing

SKF GE100ES-2RS spherical plain bearings | 100x150x70mm

Also known as : GE100ES-2RS, GE100-DO-2RS

  • Inside Diameter: 100 mm
  • Outside Diameter: 150 mm
  • Width: 70 mm
  • Basic dynamic load rating: 610 kN
  • Basic static load rating: 3050 kN

Inquire Now

SKF GE100ES-2RS Bearing

SKF GE100ES-2RS Bearing details

number GE100ES-2RS
Type Radial spherical plain bearings
d 100 mm
D 150 mm
B 70 mm
C 55 mm
α 6 °
dk 130 mm
b 11.3 mm
b1 11.3 mm
M 5 mm
r1 min. 1 mm
r2 min. 1 mm
da min. 107.8 mm
da max. 109.5 mm
Da min. 131 mm
Da max. 143.2 mm
ra max. 1 mm
rb max. 1 mm
Calculation data
Basic dynamic load rating C 610 kN
Basic static load rating C0 3050 kN
Specific dynamic load factor K 100 N/mm²
Specific static load factor K0 500 N/mm²
Material constant KM 330
Mass 4.4 kg

As SKF bearing distributor, Nodes bearings have SKF GE100ES-2RS spherical plain bearings in stock.

A characteristic feature of SKF steel/steel radial spherical plain bearings is the outer ring, which is intentionally fractured so that it can be sprung apart to enable the inner ring to be inserted
