FAG QJ319-N2-MPA Bearing

FAG QJ319-N2-MPA bearings | Dimensions: 95x200x45mm

Also known as : QJ319-N2-MPA

• Inside Diameter: 95 mm
• Outside Diameter: 200 mm
• Width: 45 mm
• Basic dynamic load rating: 285 kN
• Basic static load rating: 315 kN

Inquire Now

FAG QJ319-N2-MPA Bearing

Number	QJ319-N2-MPA
Type	Four point contact bearings main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
d	95mm
D	200mm
B	45mm
	45°	Groove angle
a	103mm
an	11,7mm
bn	10,5mm
D1	165,4mm
Da max	186mm
d1	131,2mm
da min	109mm
ra max	2,5mm
rmin	3mm
rn	2mm
α	35°	Contact angle
m	7,45kg	Mass
Cr	285000N	Basic dynamic load rating, radial
C0r	315000N	Basic static load rating, radial
Cur	14500N	Fatigue limit load, radial
nG	59001/min	Limiting speed
nϑr	32501/min	Reference speed

Nodes bearings have FAG QJ319-N2-MPA bearings in stock, FAG bearings, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots.
