SKF NATR30 Bearing

SKF NATR30 support roller bearings | 62x30x29mm

Also known as : NATR30

  • Inside Diameter: 62 mm
  • Outside Diameter: 30 mm
  • Width: 29 mm
  • Basic dynamic load rating: 22.9 kN
  • Basic static load rating: 37.5 kN

Inquire Now

SKF NATR30 Bearing

SKF NATR30 Bearing details

number NATR30
Type Support rollers
D 62 mm
d 30 mm
C 28 mm
B 29 mm
d1 51 mm
r1,2 min. 1 mm
Calculation data
Basic dynamic load rating C 22.9 kN
Basic static load rating C0 37.5 kN
Fatigue load limit Pu 4.55 kN
Maximum dynamic radial loads Fr max. 26.5 kN
Maximum static radial loads F0r max. 38 kN
Limiting speed 1800 r/min
Mass 0.47 kg

As SKF bearing distributor, Nodes bearings have SKF NATR30 Support rollers in stock.
